PROFESSIONAL DJ MEDIA PLAYER
7-inch HD display with multi-touch gestures
24-bit/96kHz digital audio outputs
Dual-layer playback with individual audio outputs
Plays uncompressed audio formats (FLAC, ALAC, WAV)
8 multifunction performance pads for Cues, Loops, Slices and Rolls
8” rugged metal jog wheel with HD central display
Customizable RGB color around the jog wheel
(3) USB and (1) SD input for music playback
LAN output to link to up to four players
Syncs to iTunes, Serato DJ Pro, Traktor and Rekordbox collections
Import Rekordbox® files and database content from an inserted USB/SD, directly into the SC5000
StagelinQ connection to control AV, lighting, video and Show effects
Audio
Analog Output: 2.0 Vrms (0 dBFS, 1 kHz)
Dynamic Range: 116 dB
Distortion (THD+N): < 0.0015%
Frequency Range: 22–22,000 Hz
Digital Output:
Sampling Rate: 96 kHz
Bit Depth: 24-bit
Platter
8.0” / 203 mm (diameter)
Metal construction with display & touch-capacitive circuitry
Display
Main:
7.0” / 178 mm (diagonal)
6.0” x 3.6” / 152 x 91 mm (width x height)
Full-color LED-backlit display with touchinterface
Platter:
2.2” / 56 mm (diameter)
Full-color LED-backlit display
Connections
(2) RCA output pairs; (2) coaxial digital outputs; (1) 1/8” (3.5 mm) mini TS input (remote start); (3) USB Type-A ports (for USB drives) (Rear-panel ports supply 900mA for USB 3.0 devices, 500 mA for USB 2.0 devices. Frontpanelport supplies 500 mA for USB 2.0 devices only.); (1) USB Type-B port (for computer connection); (1) SD card slot; (1) Ethernet link port; (1) IEC power input
