Electro-Voice ELX200-12SP-W 12" Passive Subwoofer

SKU: ELX20012SPW
Regular price $899.00 inc. VAT





ELX200-12S

12" Passive Subwoofer

  • 1600 W (peak), 129 dB peak SPL utilizing high sensitivity transducer designed and engineered by EV for maximum punch.
  • High-output EVS-12L woofer designed to exacting specifications for superior durability and exceptional low-frequency reproduction.
  • System reliability verified with over 500 hours of abuse testing and endurance testing.
  • Ideal for portable and installed applications. Lightweight, compact 15 mm wood enclosure with internal bracing with durable polyurea top-coat finish.
  • Professional-grade hardware: integrated M20 threaded pole mount plate and two-handle design for easy lifting.

The ELX series is designed to deliver an unprecedented combination of sound quality, portability and durability at its price point. All-new custom components—tested to levels far exceeding the industry norm—make ELX200 a robust workhorse capable of handling real-world abuse and professional applications beyond the capability of competitors’ products in its category.

Every aspect of ELX200 is designed for ideal results as part of the whole - the acoustical, electrical and mechanical components all work together seamlessly. The subwoofers pack powerful low-frequency output into a surprisingly compact footprint, and feature tuned 15 mm thick wood enclosures with a premium top-coat finish. The proprietary features that have made the other members of the EV portable speaker family a go-to for best-in-class performance are also present.

EV's industry-leading quality and testing procedures yield efficient transducer design and meaningful specs, resulting in components that deliver accurate, linear response at the system’s highest output levels. Translation: loud and clear all the way up to the limit. Unified in one of the strongest full-range composite enclosures ever built by EV. The ELX200 is established as the new benchmark for toughness - both acoustically and physically; maximum efficiency with maximum toughness.


Weight Net 44.53lbs (20.2kg)
Depth 17.99" (457mm)
Width 17.52" (445mm)

Height 15.63" (397mm)
Available Color Black or White
Axial Sensitivity (SPL, 1 W @ 1 m) 93dB
Connector Type Dual NL4
Enclosure Material 15 mm plywood with durable polyurea top-coat finish
Family ELX200
Frequency Range (-10 dB) 33 Hz - 300 Hz
Frequency Response (-3 dB) 42 Hz - 220 Hz
Grille 18 AWG steel with powdercoat
HF Transducer
LF Transducer EVS-12L 300 mm (12 in)
Max. SPL/1m (calc) 129dB
Minimum Impedance 6.9?
Nominal Impedance 8 ??
Power Handling (Continuous / Peak) 400 W/1600W
Power Rating 1600W
Recommended High-Pass Frequency 42Hz
Shipping Weight 44.53lbs (20.2kg)
Speaker Type Subwoofer
Suspension
Woofer Size 12inch
