Home » RCF NX45-A Active 15" 2-way Powered Speaker w/ 4" NEO HF
RCF

RCF NX45-A Active 15" 2-way Powered Speaker w/ 4" NEO HF

SKU: NX45-A
$1,899.00 inc. VAT
-24% $2,499.00 $1,899.00 inc. VAT
NX 45-A
ACTIVE TWO WAY MULTIPURPOSE SPEAKER
  • 1400 W 2-WAY CLASS-D AMPLIFIER
  • 133 DB SPL MAX
  • 45 – 20000 HZ FREQUENCY RANGE
  • 90° X 50° CONSTANT DIRECTIVITY COVERAGE
  • 1400 W 2-way class-D amplifier
  • 133 dB SPL Max
  • 45 – 20000 Hz Frequency Range
  • 90° x 50° constant directivity coverage
  • 15" neodymium woofer, 3.5" voice coil
  • Horn loaded 4.0''neodymium c. driver
  • Multiple rigging points
The NX 45-A is an active speaker specifically designed to be the everyday tool for rental companies and professional musicians. It’s one of the most flexible speaker for deploying high-power and pristine sound as a stand-alone FOH system or as a satellite (with subwoofer) but either as a stage monitor or a front, down or side fill speaker.
SPECIFICATIONS
Acoustical specifications
FREQUENCY RESPONSE:
45 Hz ÷ 20000 Hz

MAX SPL @ 1M:
133 dB

HORIZONTAL COVERAGE ANGLE:
90°

VERTICAL COVERAGE ANGLE:
50°
Transducers
COMPRESSION DRIVER:
1.4'' neo, 4.0'' v.c

WOOFER:
15'' neo, 3.5'' v.c
Input/Output section
INPUT SIGNAL:
bal/unbal

INPUT CONNECTORS:
XRL, Jack

OUTPUT CONNECTORS:
XLR

INPUT SENSITIVITY:
-2 dBu/+4 dBu

MIC. INPUT SENSITIVITY:
-32 dBu
Processor section
CROSSOVER FREQUENCIES:
650 Hz

PROTECTIONS:
Thermal, RMS

LIMITER:
Soft Limiter

CONTROLS:
Volume, Boost, Mic/Line
Power section
TOTAL POWER:
1400 W Peak, 700 W RMS

HIGH FREQUENCIES:
400 W Peak, 200 W RMS

LOW FREQUENCIES:
1000 W Peak, 500 W RMS

COOLING:
Convection

CONNECTIONS:
Powercon IN/OUT
Standard compliance
CE MARKING:
Yes
Physical specifications
CABINET/CASE MATERIAL:
Baltic birch plywood

HARDWARE:
5 x M10, 4 x quick lock

HANDLES:
2 Side

POLE MOUNT/CAP:
Yes

GRILLE:
Steel

COLOR:
Black
Size
HEIGHT:
707 mm / 27.83 inches

WIDTH:
418 mm / 16.46 inches

DEPTH:
402 mm / 15.83 inches

WEIGHT:
24 kg / 52.91 lbs
Shipping informations
PACKAGE HEIGHT:
760 mm / 29.92 inches

PACKAGE WIDTH:
480 mm / 18.9 inches

PACKAGE DEPTH:
460 mm / 18.11 inches

PACKAGE WEIGHT:
27 kg / 59.52 lbs
