RCF

RCF P8015S Passive 15" Outdoor Weatherproof Subwoofer (8 ohm, IP55)

SKU: P8015S
$1,099.00 inc. VAT
-27% $1,499.00 $1,099.00 inc. VAT
P 8015S
WEATHERPROOF SUBWOOFER
  • 132 DB MAX SPL, 800 W RMS
  • WEATHERPROOF IP55 CABINET WITH UV PROTECTION
  • ROTOMOULDED SINGLE PIECE CABINET
  • ALUMINUM GRILLE AND 316P STAINLESS STEEL BRACKET
  • 132 dB max SPL, 800 W RMS
  • Weatherproof IP55 cabinet with UV protection
  • Rotomoulded single piece cabinet
  • Aluminum grille and 316P stainless steel bracket
  • Arrayable bass-reflex compact subwoofer
  • 15" high power neodymium woofer with 4" voice coil
  • 12 brass suspension points (M10)
P 8015S is a weatherproof bass reflex subwoofer equipped with a 15" low-frequency neodymium transducer with a 4" voice coil offering power and efficiency for a variety of professional outdoor or indoor applications. The P 8015S has been specifically designed to reinforce the low-frequency range in P Series speakers array systems. The single-piece roto-molded cabinet is fully UV protected and meets IP-55 standard requirements (International Protection Rating), equipped with M10 brass inserts (12x) and a durable and corrosion-resistant stainless steel U-Bracket and spacers (2x) for 90° mounting. The aluminum grille cover is powder coated with a water-repellent fabric backing.
SPECIFICATIONS
Acoustical specifications
FREQUENCY RESPONSE (-10DB):
50 Hz ÷ 200 Hz

MAX SPL @ 1M:
132 dB

SYSTEM SENSITIVITY:
97 dB
Power section
NOMINAL IMPEDANCE (OHM):
8 ohm

POWER HANDLING:
800 W RMS

PEAK POWER HANDLING:
3200 W PEAK

RECOMMENDED AMPLIFIER:
1600 W
Transducers
WOOFER:
15'' neo, 4.0'' v.c

NOMINAL IMPEDANCE (OHM):
8 ohm

SENSITIVITY (DB, 1W @ 1M):
97 dB, 1W @ 1m
Input/Output section
INPUT CONNECTORS:
Neoprene Cable
Standard compliance
IP PROTECTION GRADE:
IP 55

CE MARKING:
Yes
Physical specifications
COLOR:
Black

HARDWARE:
12 x M10 + U bracket and pair of spacers

GRILLE:
Aluminum with waterproof clothing

CABINET/CASE MATERIAL:
PE Low Density
Size
WIDTH:
463 mm / 18.23 inches

DEPTH:
433 mm / 17.05 inches

HEIGHT:
463 mm / 18.23 inches

WEIGHT:
16.5 kg / 36.38 lbs
Shipping informations
PACKAGE WEIGHT:
21.5 kg / 47.4 lbs

PACKAGE DEPTH:
489 mm / 19.25 inches

PACKAGE WIDTH:
489 mm / 19.25 inches

PACKAGE HEIGHT:
519 mm / 20.43 inches
